| DIMENSION |
|
|---|---|
| WATTAGE | 5W | 7W |
| LUMEN OUTPUT | 5W 282-360 lm (2700K) | 321-390 lm (3000K) 7W 338-432 lm (2700K) | 383-468 lm (3000K) |
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 20° | 25° | 30° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
AXEL
د.إ310.00
- AXEL92F
- AXEL82F
- AXEL184F
- AXEL174F
- AXEL269F
- AXEL259F
- AXEL130F
- AXEL134F
- AXEL242F
- AXEL247F
- AXEL356F
- AXEL360F
| DIMENSION |
|
|---|---|
| WATTAGE | 5W | 7W |
| LUMEN OUTPUT | 5W 282-360 lm (2700K) | 321-390 lm (3000K) 7W 338-432 lm (2700K) | 383-468 lm (3000K) |
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 24° | 38° | 15×30° |
| IP RATING | IP20 | IP54 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 5W | 7W |
| LUMEN OUTPUT | 5W 282-360 lm (2700K) | 321-390 lm (3000K) 7W 338-432 lm (2700K) | 383-468 lm (3000K) |
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 20° | 25° | 30° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 2x5W | 2x7W |
| LUMEN OUTPUT | 2x5W 564-720 lm (2700K) | 642-780 lm (3000K) 2x7W 676-864 lm (2700K) | 766-936 lm (3000K)
|
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 20° | 25° | 30° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 3x5W | 3x7W |
| LUMEN OUTPUT | 3x5W 846-1080 lm (2700K) | 963-1170 lm (3000K) 3x7W 1014-1296 lm (2700K) | 1149-1404 lm (3000K)
|
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 20° | 25° | 30° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 3x5W | 3x7W |
| LUMEN OUTPUT | 3x5W 846-1080 lm (2700K) | 963-1170 lm (3000K) 3x7W 1014-1296 lm (2700K) | 1149-1404 lm (3000K)
|
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 20° | 25° | 30° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 8W | 10W | 12W | 15W |
| LUMEN OUTPUT | 8W 621-671 lm (2700K) | 642-693 lm (3000K) 10W 696-789 lm (2700K) | 753-799 lm (3000K) 12W 821-932 lm (2700K) | 837-888 lm lm (3000K) 15W 889-1020 (2700K) | 939-1033 lm (3000K)
|
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 24° | 38° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 8W | 10W | 12W | 15W |
| LUMEN OUTPUT | 8W 621-671 lm (2700K) | 642-693 lm (3000K) 10W 696-789 lm (2700K) | 753-799 lm (3000K) 12W 821-932 lm (2700K) | 837-888 lm lm (3000K) 15W 889-1020 (2700K) | 939-1033 lm (3000K)
|
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 24° | 38° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 2x8W | 2x10W | 2x12W | 2x15W |
| LUMEN OUTPUT | 2x8W 1242-1292 lm (2700K) 1284-1346 lm (3000K) 2x10W 1392-1498lm (2700K) 1506-1578 lm (3000K) 2x12W 1642-1704 lm (2700K) 1674-1744 lm (3000K) 2x15W 1778-1864 lm (2700K) 1878-1950 lm (3000K) |
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 24° | 38° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 2x8W | 2x10W | 2x12W | 2x15W |
| LUMEN OUTPUT | 2x8W 1242-1292 lm (2700K) 1284-1346 lm (3000K) 2x10W 1392-1498lm (2700K) 1506-1578 lm (3000K) 2x12W 1642-1704 lm (2700K) 1674-1744 lm (3000K) 2x15W 1778-1864 lm (2700K) 1878-1950 lm (3000K) |
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 24° | 38° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 3x8W | 3x10W | 3x12W | 3x15W |
| LUMEN OUTPUT | 3x8W 1863-1938 lm (2700K) 1926-2019 lm (3000K) 3x10W 2088-2247 lm (2700K) 2259-2367 lm (3000K) 3x12W 2463-2556 lm (2700K) 2511-2616 lm (3000K) 3x15W 2667-2796 lm (2700K) 2817-2925 lm (3000K) |
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 24° | 38° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
| DIMENSION |
|
|---|---|
| WATTAGE | 3x8W | 3x10W | 3x12W | 3x15W |
| LUMEN OUTPUT | 3x8W 1863-1938 lm (2700K) 1926-2019 lm (3000K) 3x10W 2088-2247 lm (2700K) 2259-2367 lm (3000K) 3x12W 2463-2556 lm (2700K) 2511-2616 lm (3000K) 3x15W 2667-2796 lm (2700K) 2817-2925 lm (3000K) |
| CCT | 2700K | 3000K | 4000K | 5000K | 6000K also available in custom color temperature |
| CRI | 90 |
| OPTICAL | 15° | 24° | 38° |
| IP RATING | IP20 |
| CONTROL | NON-DIM | PHASE | 1-10V | DALI | BLUETOOTH |
